ANHUI YOCHON NEW MATERIALS CO.,LTD
| Place of Origin: | Anhui(China) |
|---|---|
| Brand Name: | YOCHON |
| Certification: | 91340122358555035H |
| Model Number: | YC-AC-181218-29(YC8868) |
| Minimum Order Quantity: | 100KG |
| Price: | Negotiable |
| Packaging Details: | N. W. 25kg/bag, 1000kg/pallet ,Composite Plastic Bag |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100,000 TONS/YEAR |
| Material: | TGIC Curing Resin | Property: | Super Durable Resin |
|---|---|---|---|
| Packaging: | Composite Plastic Bag | Specification: | 93:7 TGIC Resin |
| Form: | Solid State | Color: | Transparent |
| High Light: | Non Blooming tgic powder coat,solid state polyester powder coat,TGIC Polyester Powder Coating Superdurable |
||
Product Overview
Polyester resin is short for saturated polyester adhesive. The saturated polyester adhesive is mainly
composed of saturated polyester resin, initiator, accelerator, filler, thixotropic agent and so on. The
polyester resin produced by our company is mainly used for the coating of metal parts, and is widely
used in household appliances, instruments, auto parts, oil pipelines, etc. This is a fast-growing raw
material for coatings.
It is a kind of high performance engineering plastics, used on a wide range of application.Different
types and characteristics of polyester resins can be synthesized by different multi-acid and polyol.
Polyester resin of straight-chain structure is produced using both alcohol and acid of straight chain
structure.
Production Parameter
| TGIC Polyester Powder Coating Superdurable Resin Manufacturers General Purpose | ||||||
| Code | Type | Acid Value mgKOH/g | Viscosity mPa.s/200℃ |
T g ℃ |
Curing ℃/min |
Properties |
| YC8868 | 93:7 | 30-38 | 5500-7500 | ≥69 | 200/10-15 | High Tg,high gloss, high leveling, excellent weather resistance and storage stability |
|
YC8868 is carboxylated polyester resin for 93:7 TGIC curing powder coating; high TG, high flow, high gloss. super weatherability and storage ability. Widely used in aluminum profile |
||||||
Similar Produtions Dispaly
| Code | Type | Acid Value mgKOH/g | Viscosity mPa.s/200℃ |
T g ℃ |
Curing ℃/min |
Properties |
| YC8011 | 93:7 | 29-36 | 4000-6000 | ≥64 | 200/10 | Economical resin, excellent leveling and mechanical properties, good flexibility, |
| YC8012 | 93:7 | 29-34 | 5200-7200 | ≥63 | 200/10 | Economical resin,flow resistant, excellent mechanical properties |
| YC8016 | 93:7 | 29-36 | 4500-6500 | ≥64 | 200/10 | Economical resin,good leveling and mechanical properties |
| YC8200 | 93:7 | 29-34 | 4500-6500 | ≥62 | 200/10 | Excellent leveling, good mechanical properties and anti-aging performance; suitable for black high gloss,matt effect, slow curing |
| YC8211 | 93:7 | 28-36 | 3500-6000 | ≥65 | 200/10 | Excellent leveling and superior mechanical performance |
| YC8401 | 94:6 | 28-32 | 6000-8000 | ≥63 | 200/10 180/15 | Economical resin, excellent mechanical properties |
| YC8240 | 90:10 | 48-55 | 6000-9000 | ≥65 | 200/10 | High acid resin, high hardness, excellent comprehensive performance |
| YC8511 | 96:3 | 20-26 | 4500-5500 (220℃) |
≥65 | 200/10 | Excellent mechanical properties,suitable for home appliance |
| YC8600 | 93:7 | 30-36 | 6000-8000 | ≥65 | 200/10 | Excellent overall performance, widely used in aluminum profile |
| YC8666 | 93:7 | 33-38 | 6000-8000 | ≥67 | 200/10 | Excellent overall performance, widely used in aluminum profile, excellent resistance to water boiling and salt spray |
| YC8855 | 93:7 | 30-36 | 8000-10000 (220℃) |
≥70 | 200/10 | High temperature resistance(≤300℃), yellowing resistance, good leveling and mechanical properties, excellent weather resistance |
| YC8866 | 93:7 | 30-36 | 5500-7500 | ≥67 | 200/10 | High Tg,high gloss, good leveling, excellent weather resistance and storage stability |
| YC8868 | 93:7 | 30-38 | 5500-7500 | ≥69 | 200/10-15 | High Tg,high gloss, high leveling, excellent weather resistance and storage stability |
| YC8900 | 93:7 | 33-38 | 3500-5500 | ≥63 | 200/15 | Slow cure resin, excellent flow, for metal powder coating and architectural |
| For Heat Transfer Polyester Resin | ||||||
| Code | Type | Acid Value mgKOH/g | Viscosity mPa.s/200℃ |
T g ℃ |
Curing ℃/min |
Properties |
| YC8205 | 92:8 | 38-44 | 3500-5000 | ≥63 | 200/10 | Excellent leveling, excellent mechanical properties and aging resistance, suitable for matt heat transfer |
| YC8206 | 92:8 | 40-45 | 4000-6000 | ≥69 | 200/10 | Good leveling, mechanical properties and weathering resistance, suitable for heat transfer |
| YC8208 | 93:7 | 37-40 | 7000-9000 | ≥68 | 200/10 | High gloss and hardness, excellent mechanical properties; suitable for heat transfer |
| Matt Dry Blend/One Shot System Standard Durable Polyester Resin | ||||||
| Code | Type | Acid Value mgKOH/g | Viscosity mPa.s/200℃ |
T g ℃ |
Curing ℃/min |
Properties |
| YC8501 | 96:4 | 20-26 | 5000-9000 | ≥60 | 200/10 | Low acid resin for dry blend with 8502 to reach matt effect20-35%,used in matt weatherability powder coating |
| YC8502 | 90:10 | 48-53 | 4000-5500 | ≥67 | 200/10 | High acid resin, dry blend with 8501 to reach matt effect 20-35%, used in matt weatherability powder coating |
| TP009 | 93:7 | 30-36 | 4500-6500 | ≥60 | 220/15 | Good weather resistance and flexibility; can get dead matt effect with GMA |
| Superdurable Polyester Resin | ||||||
| Code | Type | Acid Value mgKOH/g | Viscosity mPa.s/200℃ |
T g ℃ |
Curing ℃/min |
Properties |
| YC8588 | 93:7 | 29-34 | 4500-6500 | ≥64 | 200/15 | Super durable resin |
| YC8550 | 90/10 | 48-55 | 3500-7000 | ≥64 | 200/15 | Superdurable high acid resin, drying blend with YC8533 to reach matt |
| YC8533 | 93:7 | 30-35 | 2000-4000 | ≥62 | 200/15 | Superdurable, high flow, can dry blend with YC8550 to reach matt |
| YC8525 | 96:4 | 18-25 | 3000-5000 | ≥62 | 200/15 | Superdurable, high flow, can dry blend with YC8550 to reach matt |
| Low Temperature Curing Polyester Resin | ||||||
| Code | Type | Acid Value mgKOH/g | Viscosity mPa.s/200℃ |
T g ℃ |
Curing ℃/min |
Properties |
| YC8700 | 93:7 | 30-36 | 4500-6500 | ≥60 | 160/15 | Low temperature fast curing resin, good leveling and mechanical properties |
| YC8718 | 93:7 | 30-36 | 3000-5000 | ≥60 | 160/15 | Low temperature fast curing resin, no blooming |
